GP413
Pull-up Seal with Metal Insert
The GP413 Metal Clip Strap Seal is a high-security, durable sealing solution specifically developed for applications requiring a long strap length. With a length of 490 mm, it is the preferred choice for secure sealing of large-scale applications such as tankers, food transport vehicles, logistics containers, and similar applications.
The metal-clipped locking mechanism ensures high retention and strong resistance to tampering after sealing. This ensures that product security is maintained at the highest level during transportation and storage processes.
The flexible strap design allows for easy application to various diameters and attachment points, while the robust body construction maintains performance even under harsh field conditions. It offers a reliable solution particularly in sectors with high safety and hygiene requirements, such as fuel tankers and food logistics.
The GP413 enhances operational safety through its practical application, robust locking system, and long-length advantage, while also providing significant benefits to businesses in terms of both control and traceability.
Pull-up Seal with Metal Insert Product Features
Belt Seal Body with Metal Clip is made of Polypropylene (PP) material.
For extra security, a stainless steel clip is added to the stopper by ultrasonic welding.
Company name/logo and serial numbers up to 13 digits can be printed.
Laser printing and thermal printing options are available as marking methods.
Barcode or QR code printing can be done for mobile applications (Code128, Int 2/5, Code 39 etc.)
Shipped in groups of 10.
Tensile Strength 30 Kgf
Operating Temperature: -20°C / +80°C
Pull-up Seal with Metal Insert Product Details
Metal clip security
The stainless steel clip, ultrasonically welded into the stopper, prevents it from opening under strain; tampering attempts are instantly visible.
PP body, long strap
Lightweight and durable polypropylene (PP) body, 490mm overall length
Marking & serial number
With laser or thermal printing, the company name/logo and 13-digit serial number are permanently engraved, facilitating traceability and batch tracking.
Barcode / QR code integration
Code 128, Interleaved 2/5, Code 39 barcode or QR printing is supported for mobile applications, increasing reading speed and accuracy.
Usage Areas
- Oil Trucks
- Trucks
- Cash-in Transit
- Sacs / Bags
- Food Industry
Pull-up Seal with Metal Insert Color Options
For different colors, please contact our sales team.
Blue
Pastel Blue
Red
Pastel Red
Green
Pastel Green
Pastel Yellow
Pastel Orange
White
Pull-up Seal with Metal Insert Technical Specifications
| Feature | Value | Unit | Description |
|---|---|---|---|
| Product | GP413 Seal with Metal Insert | – | Plastic strap type security seal |
| Body material | Polypropylene (PP) | – | Heavyweight, flexible and durable |
| Safety insert | Stainless steel | – | Inserted into the chamber with ultrasonic welding |
| Marking methods | Laser, Thermal | – | Company name/logo and serial number |
| Serial number | 13 digits | – | Permanent marking |
| Coding | Barcode / QR Code | – | Code 128, Interleaved 2/5, Code 39, etc. |
| Packaging | Group of 10 | – | Standard shipping method |
| Tensile strength | 30 | Kgf | Mechanical performance rating |
| Operating temperature (min) | -20 | °C | PP for body |
| Operating temperature (max) | +80 | °C | PP for body |
Pull-up Seal with Metal Insert Technical Drawings
You can click on the image to view the product's technical drawings in detail.
Pull-up Seal with Metal Insert About Frequently Asked Questions
- What is the GP413 belt seal used for?
The GP413 is a heavy duty belt seal designed for high security applications. The metal locking part provides increased durability and tamper resistance. This makes it an ideal solution for logistics, transportation and utility seals.
- What are the size options of the GP413?
GP413 is available as a single model with a length of 490 mm. The tail diameter is 3.7 mm and the breaking strength is over 30 Kgf.
- What distinguishes the GP413 from other seals?
The metal part in the locking mechanism provides a stronger grip and increased security compared to standard all-plastic seals. Combined with durable materials and precise build quality, the GP413 offers reliable tamper indication and consistent sealing performance in a variety of environments. Also, the GP413 is one of the longest belt seal models in our range.
- What is the Minimum Order Quantity?
1000 pieces.
